美国HOKE阀门管件现货

上海达琼流体科技有限公司*销售HOKE产品，源头供应美国HOKE产品备件，价格优惠，现货供应，品质保证，采购首选
美国HOKE阀门产品系列：美国HOKE针型阀、美国HOKE安全阀、美国HOKE计量阀、美国HOKE单向阀、美国HOKE球阀、美国HOKE仪表阀、美国HOKE过滤器、美国HOKE阀组、美国HOKE旋塞阀、美国HOKE取样钢瓶、美国HOKE快速接头、美国HOKE不锈钢管、美国HOKE软管、美国HOKE接头和配件等


QQ：---
地址：上海市奉贤区五四公路4399号
针型阀-美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：用于钢瓶阀门；仪表控制盘；实验工厂的腐蚀性液体和高压系统；研究实验室
·*大使用压力：413BAR @ 21 ℃
·操作温度：-65℃ 到 +232℃
·内孔径：4.8mm
·Cv 值：0.45
·特点：316 不锈钢和锰乃尔合金材料；金属手柄和塑料手柄备选；Dyna-Pac 密封在阀杆螺纹下面保证无泄漏密封；无旋转阀杆球头保证长时间的使用寿命；加硬阀杆螺纹保证长寿命。
1711G4Y
1711M4Y
1711L4Y
1711F4Y
1711G6Y
1711G8YMM
1711M4M
1711F4M
1751G4Y
1751M4Y
1751L4Y
1751F4Y
1751G6Y
1751G8YMM
1751M4M
1751F4M

针型阀-美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：液压系统；高温领域到316℃；腐蚀性系统
·*大操作压力：413BAR @ 21 ℃
·操作温度：-54℃到316℃
·内孔径：4.8mm 到8.0mm
·特点：多种材料选择-316 不锈钢，黄铜，碳钢；可以选择全金属阀杆以及无旋转阀针代替Kel-F 球头以提高使用寿命；可以选择Dyna-Pak填料或高温填料；1/8 ″到1/2″连接
2112G4B
2112F4B
2112F6B
2112F8B
2112G4Y
2112F4Y
2112G6Y
2112F6Y
2112G8Y
2112L8Y
2112F8Y
2112F4E
2112F8E
2118G4Y
2118F4Y
2118F6Y
2118F8Y
2118F4E
2118F8E
2152F8B
2152F4Y
2152F8Y
2122F6B
2122F4Y

针型阀-美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：高温高压；蒸汽或腐蚀性介质；仪器成套；现场取样；计量*
·*大使用压力：413BAR
·*高使用温度：648 ℃
·内通径：2.2mm-11.1mm
·Cv 值：.12 到18
·特点：强耐腐蚀性的316 不锈钢；专利的Dyna-Pac 填料和耐高温石墨填料安装在阀杆螺纹下面保证阀杆润滑油不污染蒸汽等介质；组合阀杆设计；哈氏合金加硬或17-4PH 合金材料的无旋转阀杆球头保证可靠关断；反向密封设计。
2215G4Y
2215F4Y
2215G6Y
2215F6Y
2215G8Y
2215L84Y
2215F8Y
2215G10YMM
2215G12YMM
2232F4Y
2225F4Y

针型阀-美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：仪表管线；气体取样管线；标准计量。
·*大压力：345BAR@ 21℃
·操作温度：-54℃ 到 +232℃
·内孔径：1.5mm 到7.9mm
·Cv 值：0.07 到1.10
·特点：多种材料选择—有316 不锈钢，黄铜，碳钢；专利Dyna-Pak 密封方式提供零泄露和低扭矩操作；可以选择Kel-F,可调以及梯形阀针；面板安装时不需拆卸阀体；直线型和角型两种。
2219F4Y      2219G12E  2219N8HC
2219F8Y     2219G16E  2219N12HC
2219F12Y 2219G12EMM  2219N16HC
2219F16Y 2219G22EMM  2219P6HC
2219G4Y 2219G25EMM  2219P8HC
2219G8Y 2219N6E       2219P12HC
2219G12Y 2219N8E       2219P16HC
2219G16Y 2219N12E  2219F4M
2219G12YMM 2219N16E  2219F8M
2219G22YMM 2219P6E       2219F12M
2219G25YMM 2219P8E       2219F16M
2219N6Y    2219P12E  2219G4M
2219N8Y      2219P16E  2219G8M
2219N12Y 2219F4HC  2219G12M
2219N16Y 2219F8HC  2219G16M
2219P6Y      2219F12HC  2219G12MMM
2219P8Y     2219F16HC  2219G22MMM
2219P12Y 2219G4HC  2219G25MMM
2219P16Y 2219G8HC  2219N6M
2219F4E     2219G12HC  2219N8M
2219F8E     2219G16HC  2219N12M
2219F12E 2219G12HCMM  2219N16M
2219F16E 2219G22HCMM  2219P6M
2219G4E 2219G25HCMM  2219P8M
2219G8E     2219N6HC      2219P12M

针型阀-美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：电厂热工仪表；腐蚀性介质；仪器成套；现场取样；高温高压
·*大使用压力：276BAR
·*高使用温度：371 ℃
·内通径：7.9mm
·Cv 值：1.2
·特点：强耐腐蚀性的316 不锈钢；耐高温石墨填料安装在阀杆螺纹下面保证阀杆润滑油不污；染蒸汽等介质；组合阀杆设计； 17-4PH 合金材料的无旋转阀杆球头保证可靠关断；反向密封设计。
2813F8Y
2813G8Y
2811G4Y
2811G6Y
2811N6Y
2811G8Y
2811F8Y
2811N8Y

针型阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：仪表管线；气体取样管线；标准计量。
·*大压力：345BAR@ 21℃
·操作温度：-54℃ 到 +232℃
·内孔径：1.5mm 到7.9mm
·Cv 值：0.07 到1.10
·特点：多种材料选择—有316 不锈钢，黄铜，碳钢；专利Dyna-Pak 密封方式提供零泄露和低扭矩操作；可以选择Kel-F,可调以及梯形阀针；面板安装时不需拆卸阀体；直线型和角型两种。
3732M2B 3712G6YMM 3722M4Y 3842G6B
3732M4B 3712G8YMM 3722G6YMM 3842G8B
3732G4Y 3712G4M 3762H4B 3842G6Y
3732M4Y 3712H4M 3762M4B 3842G8Y
3742M2B 3752F2B     3762G4Y     3852F4B
3742F2B      3752G4B 3762H4Y    3852L4Y
3742G4B 3752H4B 3762M4Y 3852F4Y
3742M4B 3752M4B 3762G6YMM 3852G6Y
3742M2Y 3752G2Y 3812L4B      3852M6Y
3742F2Y      3752F2Y 3812F4B      3852G8Y
3742G4Y 3752G4Y 3812H46B 3852G10YMM
3742M4Y 3752H4Y    3812G6B 3852G12YMM
3712G2B 3752M4Y 3812M6B 3802F4B
3712M2B 3752G3YMM 3812G8B 3802L4Y
3712F2B    3752G6YMM 3812L4Y     3802F4Y
3712G4B 3752G8YMM 3812F4Y     3802L64Y
3712H4B 3752G4M 3812H46Y 3862F4B
3712M4B 3722M2B 3812G6Y 3862L4Y
3712G2Y 3722F2B      3812M6Y 3862F4Y
3712M2Y 3722H24B 3812G8Y 3862L64Y
3712F2Y      3722H4B 3812G10YMM 3912F8B
3712G4Y 3722M4B 3812G12YMM 3912G8Y
3712H4Y      3722G2Y 3812H46M 3912F8Y
3712M4Y 3722G4Y 3812G6M 3912F8E
3712G3YMM 3722H4Y    3812G8M 3952F8B

计量阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：精密计量气体或蒸汽分析；气体或水取样管线及精密标准计量；气相色谱，光谱。
·*大压力：345BAR@ 21℃
·操作温度：-54℃ 到 +232℃
·内孔径：1.19mm
·Cv 值：0.010(1°刻度)；0.024(3°刻度)
·特点：多种材料选择—有316 不锈钢，黄铜；精密的计量和重复设定能力；精确的内通径和严密的调整公差排除了滞后现象；微调游标卡尺式的手柄保证可视操作和精确流量设定；Dyna-Pac密封在阀杆螺纹下面保证无泄漏密封。
1335M4Y 1335G4B
1335G2Y 1345F2B
1335G4Y 1345H2B
1335G3YMM 1345G2B
1335G6YMM 1345G4B
1345H2Y      1345G6BMM
1345G2Y 1315H2B
1345G4Y 1315M2B
1345G3YMM 1315M4B
1345G6YMM 1315G2B
1315F2Y      1315G4B
1315M4Y 1325F2B
1315G2Y 1325H2B
1315G4Y 1325G2B
1315G3YMM 1325G4B
1315G6YMM 1325G6BMM
1325H2Y
1325G2Y
1325G4Y
1325G3YMM
1325G6YMM
1335H2B
1335M2B
1335M4B
1335G2B

计量阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：气相色谱，光谱；取样管线及精密标准计量；环保监测等。
·*大压力：345BAR@ 21℃
·操作温度：-29℃ 到 +121℃
·内孔径：.79mm
·Cv 值：0.0008
·特点：多种材料选择—有316 不锈钢，黄铜；很小的内部体积保证精密流量控制；新式的刻度显示保证清晰阅读和明确阀门位置；无旋转阀杆球头保证均匀的流量控制；随意重复流量设定可O 型环密封在阀杆下部。
1656G2YA
1656G4YA
1654G4BA
1654M4BA
1666G2YA
1666G4YA

计量阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：精密计量气体或蒸汽分析；实验室取样；气相色谱和分析。
·*大压力：207BAR@ 21℃
·操作温度：-51℃ 到 +121℃
·内孔径：1.57mm 和3.17mm
·Cv 值： 0.062(1° 刻度) ； 0.077(8° 刻度);0.270(8°刻度)
·特点：多种材料选择—有316 不锈钢，黄铜；弹簧承载式密封防止通径随意变化；Kel-F 密封保证无泄漏；1°刻度可用于精密计量；面板安装；可选刻度手柄。
2355F2Y
2355F4Y
2355G4Y
2315F2Y
2315F4Y
2315G4Y
2335F2Y
2335F4Y
2335G4Y
2311F2B
2311F4B
2321F2B
2321F4B
2331F2B
2331F4B
2331G4B
2341F2B
2341F4B

球阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：化学工艺管线;炼油;气体分配;现场取样;液压流体;蒸汽系统;低温系统。
·*大压力：172BAR@ 21℃
·操作温度：-54℃ 到 +260℃
·内孔径：4.8mm 到22.3mm
·Cv 值：1.0-38
·特点：自动补偿式阀杆密封补偿由于温度和压力变化对阀门的冲击,实现开关50,000 次无泄漏密封; 活性承载式阀杆密封确保长时间内零泄漏;防冲出阀杆;接地端子防止静电; 手柄清晰显示介质流向;安装执行机构可以实现远程控制
7C23F4Y       7C23F6Y      7C23F8Y       7C23F12Y      7C23F16Y
7C23F4Y-LT    7C23F6Y-LT    7C23F8Y-LT    7C23F12Y-LT   7C23F16Y-LT

球阀 美国HOKE（上海）达琼流体 现货供应
7G2210F4 1/4" NPT Female 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210F6 3/8" NPT Female 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210F8 1/2" NPT Female 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G4 1/4" Gyrolok 316 Stainless Steel 0.80 0.187 in4.80 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G6 3/8" Gyrolok 316 Stainless Steel 1.12 0.282 in7.20 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G8 1/2" Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G6MM 6 mm Gyrolok 316 Stainless Steel 0.53 0.156 in4.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G8MM 8 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G10MM 10 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G12MM 12 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G2210G18MM 18 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210F4 1/4" NPT Female 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210F6 3/8" NPT Female 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210F8 1/2" NPT Female 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G4 1/4" Gyrolok 316 Stainless Steel 0.80 0.187 in4.80 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G6 3/8" Gyrolok 316 Stainless Steel 1.12 0.282 in7.20 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G8 1/2" Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G6MM 6 mm Gyrolok 316 Stainless Steel 0.53 0.156 in4.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G8MM 8 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G10MM 10 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
7G4210G12MM 12 mm Gyrolok 316 Stainless Steel 2.45 0.316 in8.00 mm 3000 psig (207 Bar) -20 to 475 ºF-29 to 232 ºC
球阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：高压仪表管线;液体和气体的仪表管线；气相色谱和分析;液压标准测试；气体取样系统。
·*大压力：414BAR@ 21℃
·操作温度：-29℃ 到 +249℃
·内孔径：2.4mm 到6.4mm
·Cv 值：0.23-1.40
·特点：多种材料选择—有316 不锈钢，黄铜；浮球式设计保证压力补偿式密封和减少操作扭矩; 专利Dyna-Pak 密封方式提供零泄露和低扭矩操作;1/4 转手柄清晰显示介质流向;锻造本体确保强度;双重密封提供多重密封方式.
7155G2B 1/8" Gyrolok 1/8" Gyrolok Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.093 in2.40 mm 0.23
7155F2B 1/8" NPT Female 1/8" NPT Female Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.125 in3.20 mm 0.40
7155G4B 1/4" Gyrolok 1/4" Gyrolok Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.125 in3.20 mm 0.40
7115G4B 1/4" Gyrolok 1/4" Gyrolok Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.187 in4.70 mm 0.80
7115H4B 1/4" NPT Male 1/4" Gyrolok Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.187 in4.70 mm 0.80
7115L4B 1/4" NPT Male 1/4" NPT Female Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115F4B 1/4" NPT Female 1/4" NPT Female Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115G6B 3/8" Gyrolok 3/8" Gyrolok Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115G8B 1/2" Gyrolok 1/2" Gyrolok Brass 3000 psig at 70° F (207 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7155G2Y 1/8" Gyrolok 1/8" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.093 in2.40 mm 0.23
7155F2Y 1/8" NPT Female 1/8" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.125 in3.20 mm 0.40 7115F2Y 1/8" NPT Female 1/8" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7155G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.125 in3.20 mm 0.40
7115G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.187 in4.70 mm 0.80
7115H4Y 1/4" NPT Male 1/4" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.187 in4.70 mm 0.80
7115L4Y 1/4" NPT Male 1/4" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115F4Y 1/4" NPT Female 1/4" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115G6Y 3/8" Gyrolok 3/8" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115G8Y 1/2" Gyrolok 1/2" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7155G3YMM 3mm Gyrolok 3mm Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.093 in2.40 mm 0.23
7155G6YMM 6mm Gyrolok 6mm Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.125 in3.20 mm 0.40
7115G6YMM 6mm Gyrolok 6mm Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.187 in4.70 mm 0.80
7115G8YMM 8mm Gyrolok 8mm Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7115G10YMM 10mm Gyrolok 10mm Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40 7115G12YMM 12mm Gyrolok 12mm Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40 7115G4M 1/4" Gyrolok 1/4" Gyrolok Monel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.187 in4.70 mm 0.80
7115F4M 1/4" NPT Female 1/4" NPT Female Monel 6000 psig at 70° F (414 bar at 21° C) 0 to +300 ºF-18 to +149 ºC 0.25 in6.40 mm 1.40
7142G2B 1/8" Gyrolok 1/8" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.093 in2.40 mm 0.23
7142F2B 1/8" NPT Female 1/8" NPT Female Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.125 in3.20 mm 0.40
7142G4B 1/4" Gyrolok 1/4" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.125 in3.20 mm 0.40
7122G4B 1/4" Gyrolok 1/4" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.187 in4.70 mm 0.80
7122H4B 1/4" NPT Male 1/4" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.187 in4.70 mm 0.80
7122L4B 1/4" NPT Male 1/4" NPT Female Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122F4B 1/4" NPT Female 1/4" NPT Female Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122G6B 3/8" Gyrolok 3/8" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7142G2Y 1/8" Gyrolok 1/8" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.093 in2.40 mm 0.23
7142F2Y 1/8" NPT Female 1/8" NPT Female 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.125 in3.20 mm 0.40 7142G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.125 in3.20 mm 0.40
7122G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.187 in4.70 mm 0.80
7122H4Y 1/4" NPT Male 1/4" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.187 in4.70 mm 0.80
7122H46Y 1/4" NPT Male 3/8" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122M4Y 1/4" NPT Male 1/4" NPT Male 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in4.70 mm 1.40
7122L4Y 1/4" NPT Male 1/4" NPT Female 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122F4Y 1/4" NPT Female 1/4" NPT Female 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122G6Y 3/8" Gyrolok 3/8" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122G8Y 1/2" Gyrolok 1/2" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7142G3YMM 3mm Gyrolok 3mm Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.093 in2.40 mm 0.23
7142G6YMM 6mm Gyrolok 6mm Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.125 in3.20 mm 0.40
7122G6YMM 6mm Gyrolok 6mm Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.187 in4.70 mm 0.80
7122G8YMM 8mm Gyrolok 8mm Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7122G10YMM 10mm Gyrolok 10mm Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40 7122G4M 1/4" Gyrolok 1/4" Gyrolok Monel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.187 in4.70 mm 0.80
7122F4M 1/4" NPT Female 1/4" NPT Female Monel 1500 psig at 70° F (103 bar at 21° C) -40 to +350 ºF-40 to +176 ºC 0.25 in6.40 mm 1.40
7188G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +425 ºF-29 to +218 ºC 0.125 in3.20 mm 0.40
7188F4Y 1/4" NPT Female 1/4" NPT Female 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +425 ºF-29 to +218 ºC 0.25 in6.40 mm 1.40
7188G6Y 3/8" Gyrolok 3/8" Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +425 ºF-29 to +218 ºC 0.25 in6.40 mm 1.40
7188G8Y 1/2" Gyrolok 1/2" Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +425 ºF-29 to +218 ºC 0.25 in6.40 mm 1.40

球阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：液压标准测试；纸浆处理;实验工厂;启动系统。
·*大压力：345BAR@ 21℃
·操作温度：-29℃ 到 +177℃
·内孔径：9.5mm
·Cv 值：3.4
·特点：多种材料选择—有316 不锈钢，黄铜；选用Viton 密封环或PTFE 垫圈可增加温度和腐蚀性的兼容;高密度的PTFE 阀座可以消除低温造成的变形; 双重密封提供多重密封方式;可选择椭圆型尼龙或金属手柄;防冲出的阀杆设计.
7222F8B 1/2" NPT Female Brass 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222G8B 1/2" Gyrolok Brass 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222F6Y 3/8" NPT Female 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222F8Y 1/2" NPT Female 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222G8Y 1/2" Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222G12YMM 12 mm Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222F8M 1/2" NPT Female Monel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7222G8M 1/2" Gyrolok Monel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7223F6Y 3/8" NPT Female 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7223F8Y 1/2" NPT Female 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7223G8Y 1/2" Gyrolok 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7223G12YMM 12 mm Gyrolok 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4

球阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：高压仪表管线;液体和气体的仪表管线；气相色谱和分析;气体取样系统。
·*大压力：414BAR@ 21℃
·操作温度：-40℃ 到 +177℃
·内孔径：2.4mm 到9.5mm
·Cv 值：0.23-3.4
·特点：多种材料选择—有316 不锈钢，黄铜；椭圆型转手柄清晰显示介质流向;浮球式设计保证压力补偿式密封和减少操作扭矩; 固定的连接方式防止错误安装.
7015G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) -40 to +300 ºF-40 to +149 ºC 0.187 in4.80 mm 0.80
7015H4Y 1/4" NPT Male 1/4" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) -40 to +300 ºF-40 to +149 ºC 0.187 in4.80 mm 0.80
7015L4Y 1/4" NPT Male 1/4" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) -40 to +300 ºF-40 to +149 ºC 0.25 in6.30 mm 1.40
7015F4Y 1/4" NPT Female 1/4" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) -40 to +300 ºF-40 to +149 ºC 0.25 in6.30 mm 1.40
7015G6Y 3/8" Gyrolok 3/8" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) -40 to +300 ºF-40 to +149 ºC 0.25 in6.30 mm 1.40
7022G4B 1/4" Gyrolok 1/4" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.80
7022L4B 1/4" NPT Male 1/4" NPT Female Brass 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022F4B 1/4" NPT Female 1/4" NPT Female Brass 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022G6B 3/8" Gyrolok 3/8" Gyrolok Brass 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022G2Y 1/8" Gyrolok 1/8" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.093 in2.30 mm 0.23
7022G4Y 1/4" Gyrolok 1/4" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.80
7022H4Y 1/4" NPT Male 1/4" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.80
7022M4Y 1/4" NPT Male 1/4" NPT Male 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022L4Y 1/4" NPT Male 1/4" NPT Female 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022F4Y 1/4" NPT Female 1/4" NPT Female 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022G6Y 3/8" Gyrolok 3/8" Gyrolok 316 Stainless Steel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022G4M 1/4" Gyrolok 1/4" Gyrolok Monel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.80
7022F4M 1/4" NPT Female 1/4" NPT Female Monel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7022G6M 3/8" Gyrolok 3/8" Gyrolok Monel 1500 psig at 70° F (103 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.25 in6.30 mm 1.40
7092F8B 1/2" NPT Female 1/2" NPT Female Brass 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092G8B 1/2" Gyrolok 1/2" Gyrolok Brass 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092F6Y 3/8" NPT Female 3/8" NPT Female 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092F8Y 1/2" NPT Female 1/2" NPT Female 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092G8Y 1/2" Gyrolok 1/2" Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092F6M 3/8" NPT Female 3/8" NPT Female Monel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092F8M 1/2" NPT Female 1/2" NPT Female Monel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7092G8M 1/2" Gyrolok 1/2" Gyrolok Monel 2000 psig at 70° F (138 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7093F6Y 3/8" NPT Female 3/8" NPT Female 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7093F8Y 1/2" NPT Female 1/2" NPT Female 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7093G8Y 1/2" Gyrolok 1/2" Gyrolok 316 Stainless Steel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7093F6M 3/8" NPT Female 3/8" NPT Female Monel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7093F8M 1/2" NPT Female 1/2" NPT Female Monel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7093G8M 1/2" Gyrolok 1/2" Gyrolok Monel 5000 psig at 70° F (345 bar at 21° C) -20 to +350 ºF-29 to +177 ºC 0.375 in9.50 mm 3.4
7065G2B 1/8" Gyrolok Brass 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.093 in2.30 mm 0.15
7065G4B 1/4" Gyrolok Brass 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065F4B 1/4" NPT Female Brass 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065G6B 3/8" Gyrolok Brass 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065G2Y 1/8" Gyrolok 316 Stainless Steel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.093 in2.30 mm 0.15
7065G4Y 1/4" Gyrolok 316 Stainless Steel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065F4Y 1/4" NPT Female 316 Stainless Steel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065G6Y 3/8" Gyrolok 316 Stainless Steel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065G4M 1/4" Gyrolok Monel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065F4M 1/4" NPT Female Monel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57
7065G6M 3/8" Gyrolok Monel 500 psig at 70° F (35 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.80 mm 0.57

三通阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：仪表管线；取样系统。
·*大压力：414BAR@ 21℃
·操作温度：-18℃ 到 +179℃
·内孔径：3.2mm 到4.8mm
·Cv 值：.15 到.66
·特点：多种材料选择—有316 不锈钢，黄铜；专利Dyna-Pak 密封方式提供零泄露和低扭矩操作; 高密度的PTFE 和尼龙双重阀座可以消除低温造成的变形; 指向型手柄清晰显示介质流向
7644G4Y 1/4" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +250 ºF-18 to +121 ºC 0.187 in4.70 mm 0.56
7644F4Y 1/4" NPT Female 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +250 ºF-18 to +121 ºC 0.187 in4.70 mm 0.56
7644G6Y 3/8" Gyrolok 316 Stainless Steel 6000 psig at 70° F (414 bar at 21° C) 0 to +250 ºF-18 to +121 ºC 0.187 in4.70 mm 0.56
7654G4Y 1/4" Gyrolok 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.70 mm 0.56
7654F4Y 1/4" NPT Female 316 Stainless Steel 2000 psig at 70° F (138 bar at 21° C) 0 to +350 ºF-18 to +177 ºC 0.187 in4.70 mm 0.56


球阀 美国HOKE（上海）达琼流体 现货供应
产品简介:
·应用：液体和气体的仪表管线；高压或低压压力标定；取样系统。
·*大压力：414BAR@ 21℃
·操作温度：-54℃ 到 +177℃
·内孔径：2.36mm 到6.35mm
·Cv 值：0.23-1.44
·特点：多种材料选择—有316 不锈钢，黄铜；三重密封（DL）和弹簧承载式密封（TL）保证100,000 次开关无泄漏;活性承载式阀杆密封补偿温度变化可能产生的泄漏;接地防静电装置确保使用安全;工厂可配备执行机构提供低成本.
7115G2YDL 1/8" Gyrolok Gasketed 316 Stainless Steel 0.23 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G4YDL 1/4" Gyrolok Gasketed 316 Stainless Steel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G4MDL 1/4" Gyrolok Gasketed Monel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G6YDL 3/8" Gyrolok Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G8YDL 1/2" Gyrolok Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z6YDL 6 mm Gyrolok Gasketed 316 Stainless Steel 0.56 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z8YDL 8 mm Gyrolok Gasketed 316 Stainless Steel 1.14 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z10YDL 10 mm Gyrolok Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z10MDL 10 mm Gyrolok Gasketed Monel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7122G2YTL 1/8" Gyrolok Gasketed 316 Stainless Steel 0.23 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G4YTL 1/4" Gyrolok Gasketed 316 Stainless Steel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G4MTL 1/4" Gyrolok Gasketed Monel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G6YTL 3/8" Gyrolok Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G8YTL 1/2" Gyrolok Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z6YTL 6 mm Gyrolok Gasketed 316 Stainless Steel 0.56 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z8YTL 8 mm Gyrolok Gasketed 316 Stainless Steel 1.14 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z10YTL 10 mm Gyrolok Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z10MTL 10 mm Gyrolok Gasketed Monel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7015G2YDL 1/8" Gyrolok Welded 316 Stainless Steel 0.23 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015G4YDL 1/4" Gyrolok Welded 316 Stainless Steel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015G4MDL 1/4" Gyrolok Welded Monel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015G6YDL 3/8" Gyrolok Welded 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z6YDL 6 mm Gyrolok Welded 316 Stainless Steel 0.56 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z8YDL 8 mm Gyrolok Welded 316 Stainless Steel 1.14 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z10YDL 10 mm Gyrolok Welded 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z10MDL 10 mm Gyrolok Welded Monel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7022G2YTL 1/8" Gyrolok Welded 316 Stainless Steel 0.23 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022G4YTL 1/4" Gyrolok Welded 316 Stainless Steel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022G4MTL 1/4" Gyrolok Welded Monel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022G6YTL 3/8" Gyrolok Welded 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z6YTL 6 mm Gyrolok Welded 316 Stainless Steel 0.56 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z8YTL 8 mm Gyrolok Welded 316 Stainless Steel 1.14 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z10YTL 10 mm Gyrolok Welded 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z10MTL 10 mm Gyrolok Welded Monel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7115F4YDL 1/4" NPT Female Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115F4MDL 1/4" NPT Female Gasketed Monel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7122F4YTL 1/4" NPT Female Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122F4MTL 1/4" NPT Female Gasketed Monel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7015F4YDL 1/4" NPT Female Welded 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7022F4YTL 1/4" NPT Female Welded 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7115G2YD 1/8" Gyrolok Gasketed 316 Stainless Steel 0.23 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G4YD 1/4" Gyrolok Gasketed 316 Stainless Steel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G4MD 1/4" Gyrolok Gasketed Monel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G6YD 3/8" Gyrolok Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115G8YD 1/2" Gyrolok Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z6YD 6 mm Gyrolok Gasketed 316 Stainless Steel 0.56 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z8YD 8 mm Gyrolok Gasketed 316 Stainless Steel 1.14 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z10YD 10 mm Gyrolok Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115Z10MD 10 mm Gyrolok Gasketed Monel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7122G2YT 1/8" Gyrolok Gasketed 316 Stainless Steel 0.23 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G4YT 1/4" Gyrolok Gasketed 316 Stainless Steel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G4MT 1/4" Gyrolok Gasketed Monel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G6YT 3/8" Gyrolok Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122G8YT 1/2" Gyrolok Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z6YT 6 mm Gyrolok Gasketed 316 Stainless Steel 0.56 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z8YT 8 mm Gyrolok Gasketed 316 Stainless Steel 1.14 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z10YT 10 mm Gyrolok Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122Z10MT 10 mm Gyrolok Gasketed Monel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7015G2YD 1/8" Gyrolok Welded 316 Stainless Steel 0.23 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015G4YD 1/4" Gyrolok Welded 316 Stainless Steel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015G4MD 1/4" Gyrolok Welded Monel 0.80 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015G6YD 3/8" Gyrolok Welded 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z6YD 6 mm Gyrolok Welded 316 Stainless Steel 0.56 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z8YD 8 mm Gyrolok Welded 316 Stainless Steel 1.14 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z10YD 10 mm Gyrolok Welded 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7015Z10MD 10 mm Gyrolok Welded Monel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7022G2YT 1/8" Gyrolok Welded 316 Stainless Steel 0.23 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022G4YT 1/4" Gyrolok Welded 316 Stainless Steel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022G4MT 1/4" Gyrolok Welded Monel 0.80 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022G6YT 3/8" Gyrolok Welded 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z6YT 6 mm Gyrolok Welded 316 Stainless Steel 0.56 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z8YT 8 mm Gyrolok Welded 316 Stainless Steel 1.14 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z10YT 10 mm Gyrolok Welded 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7022Z10MT 10 mm Gyrolok Welded Monel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7115F4YD 1/4" NPT Female Gasketed 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7115F4MD 1/4" NPT Female Gasketed Monel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7122F4YT 1/4" NPT Female Gasketed 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7122F4MT 1/4" NPT Female Gasketed Monel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE
7015F4YD 1/4" NPT Female Welded 316 Stainless Steel 1.44 6000 psig at 70° F (414 Bar at 21° C) PCTFE
7022F4YT 1/4" NPT Female Welded 316 Stainless Steel 1.44 3000 psig at 70° F (207 Bar at 21° C) PTFE

球阀 美国HOKE（上海）达琼流体 现货供应
7223F6YD20 3/8" NPT Female 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Buna N
7223F6YD50 3/8" NPT Female 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Viton®
7223F6YD64 3/8" NPT Female 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Kalrez®
7223F8YD20 1/2" NPT Female 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Buna N
7223F8YD50 1/2" NPT Female 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Viton®
7223F8YD64 1/2" NPT Female 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Kalrez®
7223FS8YD20 1/2" SAE 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Buna N
7223FS8YD50 1/2" SAE 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Viton®
7223FS8YD64 1/2" SAE 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Kalrez®
7223G8YD20 1/2" Gyrolok 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Buna N
7223G8YD50 1/2" Gyrolok 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Viton®
7223G8YD64 1/2" Gyrolok 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Kalrez®
7223G12YD20 12 mm Gyrolok 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Buna N
7223G12YD50 12 mm Gyrolok 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Viton®
7223G12YD64 12 mm Gyrolok 316 Stainless Steel 3.4 0.375 in9.35 mm 5000 psig at 70° F (345 bar at 21° C) Kalrez®

球阀 美国HOKE（上海）达琼流体 现货供应
7510F4Y 1/4 in 0.37 in 2.09 in 1/2 in 1.12 in 2.13 in
7510F6Y 3/8 in 0.37 in 2.09 in 1/2 in 1.12 in 2.13 in
7510F8Y 1/2 in 0.49 in 2.38 in 1/2 in 1.12 in 2.13 in
7510F12Y 3/4 in 0.59 in 2.70 in 1/2 in 1.12 in 2.24 in
7510F16Y 1 in 0.79 in 3.25 in 0.87 in 1.38 in 2.46 in
7510F20Y 1 1/4 in 0.98 in 3.58 in 0.93 in 1.38 in 2.87 in
7510F24Y 1 1/2 in 1.26 in 3.94 in 0.93 in 1.50 in 3.09 in
7510F32Y 2 in 1.5 in 4.61 in 0.93 in 1.50 in 3.48 in

球阀 美国HOKE（上海）达琼流体 现货供应
7520F4Y Leveler 1/4 in 0.43 in 2.62 in 0.35 in 2.68 in
7520F6Y Leveler 3/8 in 0.49 in 2.62 in 0.35 in 2.68 in
7520F8Y Leveler 1/2 in 0.59 in 2.76 in 0.35 in 2.68 in
7520F12Y Leveler 3/4 in 0.59 in 3.15 in 0.35 in 2.78 in
7520F16Y Leveler 1 in 1.00 in 3.54 in 0.43 in 3.50 in
7520F4Y-OH Oval 1/4 in 0.43 in 2.62 in 0.35 in 2.68 in
7520F6Y-OH Oval 3/8 in 0.49 in 2.62 in 0.35 in 2.68 in
7520F8Y-OH Oval 1/2 in 0.59 in 2.76 in 0.35 in 2.68 in
7520F12Y-OH Oval 3/4 in 0.59 in 3.15 in 0.35 in 2.78 in
7520F16Y-OH Oval 1 in 1.00 in 3.54 in 0.43 in 3.50 in
球阀 美国HOKE（上海）达琼流体 现货供应
7520G4Y Leveler 1/4 in 0.43 in 2.62 in 0.35 in 2.68 in
7520G6Y Leveler 3/8 in 0.49 in 2.62 in 0.35 in 2.68 in
7520G8Y Leveler 1/2 in 0.59 in 2.76 in 0.35 in 2.68 in
7520G12Y Leveler 3/4 in 0.59 in 3.15 in 0.35 in 2.78 in
7520G16Y Leveler 1 in 1.00 in 3.54 in 0.43 in 3.50 in
7520G4Y-OH Oval 1/4 in 0.43 in 2.62 in 0.35 in 2.68 in
7520G6Y-OH Oval 3/8 in 0.49 in 2.62 in 0.35 in 2.68 in
7520G8Y-OH Oval 1/2 in 0.59 in 2.76 in 0.35 in 2.68 in
7520G12Y-OH Oval 3/4 in 0.59 in 3.15 in 0.35 in 2.78 in
7520G16Y-OH Oval 1 in 1.00 in 3.54 in 0.43 in 3.50 in

取样钢瓶-美国HOKE（上海）达琼流体 现货供应
HS4HDY75 1.5 in38.1 mm 75 cc4.6 in³ 0.6 lb0.3 kg 4.88 in124 mm 0.72 in18.3 mm 1/4-18 NPT
HS4HDY150 1.5 in38.1 mm 150 cc9.2 in³ 1.0 lb0.5 kg 8.25 in209.6 mm 0.72 in18.3 mm 1/4-18 NPT
HS4HDY300 2.00 in50.8 mm 300 cc18.3 in³ 1.8 lb0.8 kg 9.25 in235 mm 0.74 in18.3 mm 1/4-18 NPT
HS4HDY500 2.00 in50.8 mm 500 cc30.5 in³ 2.5 lb1.1 kg 13.88 in352.6 mm 0.74 in18.3 mm 1/4-18 NPT
HS4HDY1000 4.00 in101.6 mm 100 cc60.1 in³ 7.5 lb3.4 kg 9.5 in241.3 mm 1.0 in25.4 mm 1/4-18 NPT
HS8HDY1000 4.00 in101.6 mm 1000 cc60.1 in³ 7.5 lb3.4 kg 9.5 in241.3 mm 1.2 in30.5 mm 1/2-14 NPT
HS8HDY2250 4.00 in101.6 mm 2250 cc13.3 in³ 12.9 lb5.9 kg 17.2 in436.9 mm 1.2 in30.5 mm 1/2-14 NPT
HS8HDY1G 4.00 in101.6 mm 3785 cc231.0 in³ 20.6 lb9.4 kg 26.5 in673.1 mm 1.2 in30.5 mm 1/2-14 NPT
HS4HDY150-TPED 1.5 in38.1 mm 150 cc9.2 in³ 1.0 lb0.5 kg 8.25 in209.6 mm 0.72 in18.3 mm 1/4-18 NPT
HS4HDY300-TPED 2.00 in50.8 mm 300 cc18.3 in³ 1.8 lb0.8 kg 9.25 in235 mm 0.74 in18.3 mm 1/4-18 NPT
HS4HDY500-TPED 2.00 in50.8 mm 500 cc30.5 in³ 2.5 lb1.1 kg 13.88 in352.6 mm 0.74 in18.3 mm 1/4-18 NPT
HS4HDY1000-TPED 4.00 in101.6 mm 100 cc60.1 in³ 7.5 lb3.4 kg 9.5 in241.3 mm 1.0 in25.4 mm 1/4-18 NPT

8200 系列Roto-fold 球阀阀组 美国HOKE（上海）达琼流体
产品简介:
·应用：差压变送器。
·*大压力：414BAR@ 21℃
·操作温度：-18℃ 到 +149℃
·特点：强耐腐蚀性的316 不锈钢材料；可更换的Kel-F 阀座延长使用寿命; 可以使小圆棒通过泄放阀孔清洗检查;1/4 转手柄清晰显示介质流向;可以选用凸轮手柄保证阀组开关顺序

8100 系列Trifold 针阀阀组 美国HOKE（上海）达琼流体
产品简介:
·应用：差压变送器。
·*大压力：414BAR@ 21℃
·操作温度：-54℃ 到 +316℃
·特点：强耐腐蚀性的316 不锈钢材料；可选用两件式无旋转阀杆球头设计或Kel-F 阀头;Dyna-Pac 填料安装在阀杆螺纹下面保证密封；可代替316 不锈钢阀座以延长使用寿命;Dyna-Pac 填料和耐高温石墨填料阀座；可以选择螺纹或法兰出口连接。

8000 系列2,3,5 阀阀组 美国HOKE（上海）达琼流体
产品简介:
·应用：差压变送器。
·*大压力：414BAR@ 21℃
·操作温度：-55℃ 到 +316℃
·特点：可以远程独立安装;直向安装减少安装空间和接头数量;2,3,5 阀组可以满足多方位控制和计量;标准的背向密封;独特的密封设计;非旋转球头设计;锁定式阀盖。

6700 系列安全放泄阀 美国HOKE（上海）达琼流体
产品简介:
·应用：用于HOKE 钢瓶的过压保护.
·多种爆破膜片压力： 97-110BAR@ 21℃;124-138BAR@ 21℃; 179-207BAR@ 21℃;241-283BAR@ 21℃; 372-428BAR@ 21℃;
·自放泄压力值: 24-28BAR@ 21℃;37-41BAR@ 21℃
·操作温度：-29℃ 到 +121℃
·特点：过压时泄放后弹簧反复支撑密封;合金的*和316 不锈钢的本体保证强抗腐蚀性;色带显示满足CGA-S1.1 标准


1500 系列 锻造本体的开关阀 美国HOKE（上海）达琼流体
产品简介:
·应用：色谱和质量计量；测试车间；冷却管线
·*大操作压力：21℃ @ 13.8BAR
·操作温度：-29℃到+149℃
·孔径：3.2mm 到5.6mm
·Cv 值：.23 到 .60
·特点：有黄铜和316 不锈钢材料；弹性密封可用于真空；乒乓开关实现快速操作；整体设计


6300 系列过滤器 美国HOKE（上海）达琼流体
产品简介:
·应用：捕获介质中的小颗粒;保护设备的灵敏性;系统清洁
·*大压力：345BAR@ 21℃
·操作温度：-51℃ 到 +232℃
·过滤精度:2 到55 目
·Cv 值：.006 到0.420
·特点： 316 不锈钢滤芯;管线低温时可以在线更换滤芯;旁路易于清洗管路系统.

6100/6200 系列单向阀 美国HOKE（上海）达琼流体

产品简介:
·应用：防止倒流；液压油缸的压力保持；净化系统的排放阀。
·*大压力：414BAR@ 21℃
·操作温度：-29℃ 到 +177℃
·设定压力:0.02，0.14,0.69 到 1.7BAR
·内孔径：4.8mm 到10.7mm
·Cv 值：.3 到2.4
·特点：多种材料选择—有316 不锈钢，黄铜,碳钢，锰乃尔合金材料；球型提升设计保证反应速度快；提升阀提供了稳定的大流量；O 型环密封保证零泄漏。

XVH 系列溢流阀 美国HOKE（上海）达琼流体
产品简介:
·应用：气体传输系统;分析取样管线;气体柜纯化系统;小差压系统。
·*大压力：0 到414BAR
·操作温度：-196℃ 到 +482℃
·连接尺寸：1/4＂,3/8＂,1/2＂6mm 到14mm
·Cv 值：0.0008
·特点：当系统管线中有瞬间过大流量发生时该阀门自动关闭;自动或手动复位;可用于任何一种气体或液体;反向线圈防止放泄孔关闭

CVH 系列单向阀 美国HOKE（上海）达琼流体
产品简介:
·应用：反向压力保护;防止倒流;保护电磁阀,分析系统和减压阀等。
·*大压力：0 到414BAR
·操作温度：-196℃ 到 +482℃
·连接尺寸：1/8＂到1＂, 6mm 到25mm
·设定压力:0.03 到 1.7BAR
·Cv 值：.32 到7.4
·特点：阀体上的带色的O 型环容易识别和保证安全;弹性O型环提供软性密封和零泄漏;浮动式的O 型环持续的自清洗,避免污染物损坏密封填料;多种本体材料,可应用于多种液体和气体,*小的限流保证*大的Cv 值.

美国HOKE螺纹接头（上海）达琼流体
美国HOKE螺纹接头 美国HOKE (上海)达琼流体
产品简介:
·应用：HOKE 的螺纹接头是为过程，仪表连接设计的无泄露连接件。
·*大压力：413BAR
·操作温度：648℃
·特点：加工质量高；规格尺寸完整；多种材料（不锈钢，黄铜，锰乃尔）等可供选择；满足ANSI B1.20.1 设计标准。
